aSPIre 3-XL

aSPIre 3-XL

Solder Paste Inspection Equipment by Koh Young America, Inc (9 more products)
Download Brochure Request Quote

Note: Your request will be directed to Koh Young America, Inc

Product Specifications

Product Details

  • Part Number
    aSPIre 3-XL
  • Manufacturer
    Koh Young America, Inc

General Parameters

  • Field of View
    61.44 x 46.08 mm
  • Defects
    Offset, Bridge, Volume, Offset, Shape Deformity, Insufficient Paste, Excessive Paste, Coplanarity
  • PCB Size
    830 x 690 mm, 830 x 580 mm
  • PCB Thickness
    0.6 to 8 mm
  • PCB Weight
    10 kg
  • Imaging Speed
    29 to 63 cm²/sec
  • Height Resolution
    1 μm
  • Camera
    12 MP
  • Lighting
    IR-RGB LED Dome Style Illumination
  • X-Y Axis Resolution
    10 µm, 15 µm
  • Z-Axis Resolution
    0.37 µm
  • Net Weight
    850 kg, 900 kg
  • Overall Dimensions
    1350 x 1460 x 1727 mm
  • Note :
    Single Lane, Dual Lane
