T-961

T-961

Reflow Soldering Equipment by Taian Puhui Electric Technology CO., LTD (12 more products)

Note: Your request will be directed to Taian Puhui Electric Technology CO., LTD

The T-961 from Taian Puhui Electric Technology CO., LTD is a Reflow Soldering Equipment with Heating Zone Length 730 mm, Max Pcb Width 230 mm. More details for T-961 can be seen below.

Product Specifications

Product Details

  • Part Number
    T-961
  • Manufacturer
    Taian Puhui Electric Technology CO., LTD

General Parameters

  • Cooling Zones
    1 Zone
  • Heating Zones
    6 Zones
  • Heating Zone Length
    730 mm
  • Max Pcb Width
    230 mm
  • Control Type
    PID control
  • Conveyor Direction
    Left to Right
  • Conveyor Speed
    0 - 290 mm/min
  • Conveyor Type
    Net + chain transmission
  • Heat Type
    IR and hot air heating
  • General Power
    3.5 kW
  • Power Supply
    220V  50Hz
  • Temp Accuracy
    ±1 Degree C
  • Temp Range
    300 Degree C
  • Temperature deviation on PCB
    ± 2 Degree C
  • Net Weight
    70 kg
  • Overall Dimensions
    1000 x 466 x 445 mm
