ETON ET-R6

ETON ET-R6

Reflow Soldering Equipment by Shenzhen Eton Automation Equipment Co., Ltd (5 more products)

Note: Your request will be directed to Shenzhen Eton Automation Equipment Co., Ltd

The ETON ET-R6 from Shenzhen Eton Automation Equipment Co., Ltd is a Reflow Soldering Equipment with Heating Zone Length 2500 mm, Max Pcb Width 350 mm. More details for ETON ET-R6 can be seen below.

Product Specifications

Product Details

  • Part Number
    ETON ET-R6
  • Manufacturer
    Shenzhen Eton Automation Equipment Co., Ltd

General Parameters

  • Cooling Zones
    1 Zone
  • Heating Zones
    6 Zones
  • Heating Zone Length
    2500 mm
  • Max Pcb Width
    350 mm
  • Component Height
    25 mm
  • Conveyor Direction
    Left-to-right or Right-to-Left
  • Conveyor Height
    880±20 mm
  • Conveyor Speed
    0 to 1500 mm/min
  • Conveyor Type
    Chain + Mesh
  • Mesh Belt Width
    400 mm
  • Cooling Method
    Air cooling
  • Net Weight
    700 kg
  • Overall Dimensions
    3600 x 1000 x 1490 mm
