The JTR-1000/JTR-1000-N from Shenzhen JT Automation Equipment Co., Ltd. is a Reflow Soldering Equipment with Heating Zone Length 3890 mm, Max Pcb Width 400 mm. More details for JTR-1000/JTR-1000-N can be seen below.

Product Specifications

Product Details

  • Part Number
    JTR-1000/JTR-1000-N
  • Manufacturer
    Shenzhen JT Automation Equipment Co., Ltd.

General Parameters

  • Cooling Zones
    3 Zones
  • Heating Zones
    10 Zones
  • Heating Zone Length
    3890 mm
  • Max Pcb Width
    400 mm
  • Component Height
    25 to 30 mm
  • Control Type
    PC+PLC
  • Conveyor Direction
    Left-to-right ( Optional R to L )
  • Conveyor Height
    900±20 mm
  • Conveyor Speed
    300 to 2000 mm/min
  • Conveyor Type
    Mesh
  • Cooling Method
    Air cooling
  • Exhausting Flow Per Port
    10 m³/min
  • General Power
    10 to 11 kW
  • Power Supply
    AC 380 V 50/60 Hz
  • Startup power
    36 to 38 kW
  • Temp Range
    300 Degree C
  • Temperature control precision
    PID Close loop control + SSR driving
  • Net Weight
    2700 kg, 2800 kg
  • Overall Dimensions
    6300 x 1430 x 1530 mm
